Shape Maker 9050 and 10080 Forming machine for large conical boxes
Shape Maker 9050 and 10080 Forming machine for large conical boxes
Location:Italy
Specifications
| Manufacturer | AUTOMAZONE |
| Model | Shape Maker 9050 e 10080 |
| Condition | New |
| WORKABLE MATERIAL | Tight cardboard 300-500 g/m2 |
| Max die format (mm) | 900x500 / 1000x 800 |
| Maximum mold stroke (mm) | 850 |
| Machine sections (n.) | 7 / 8 / 7 |
| Maximum speed (pcs/min) | 60 / 45 / 45 |
| Machine weight | 4000 kg approximately |
| Supply | 400 VAC- 3P+N+T- 25/40 Kw |
| Compressed air | 6 BAR - 500 Nl/min |
